Item |
Code |
Specification |
1. Serises |
MAC10A- |
96x96mm Digital Controller |
MAC10B- |
48x96mm Digital Controller |
MAC10C- |
72x72mm Digital Controller |
MAC10D- |
48x48mm Digital Controller |
2. Input |
M |
Thermocouple (K, J, R) |
Resistance bulb (Pt100) Specified curent about 0.25mA |
I |
Curent (4~20mA, 0~20mA) Reception resistance 60W or less |
3. Control output 1 |
C |
Contact 1a 240V AC 2A (Resistance load) |
S |
Voltage pulse 13+-1~1.5V 20mA DC MAX |
I |
Curent 4~20 mA DC load resistance 500W MAX |
4. Power supply |
F- |
100-240VAC 50/60Hz |
5. Event output |
N |
None |
1 |
Event output 1(one point) Contact 1a 240A AC 2A |
2 |
Event output 1,2 (two points) Contact 1a 240A AC 2A |
6. Communication |
N |
None |
R |
RS485 |
